drylin® E stepper motor, stranded wires with JST connector and encoder, NEMA 24

1 from 4

drylin® E stepper motor, stranded wires with JST connector and encoder, NEMA 24

Installation size: NEMA24/flange dimension 60mm
Protection class: IP40
Holding torque: 3.50Nm
Nominal current: 4.20A
Motor connections: stranded wires with JST connector, encoder with JST connector

Part No.

MOT-AN-S-060-035-060-L-C-AAAC

The medium-installation-size power motor

The stepper motor impresses with its high torque in the medium speed range. The assembly dimensions are identical to the NEMA23, allowing many applications. The stepper motor works precisely, is robust, cost-effective and easy to control. It is used in inexpensive stand-alone devices, as well as automation machines and format adjustments. The motor connection has a JST connector. This protrudes 300mm from the rear part of the motor housing. The advantage of this connector is that it is more cost-effective than the metric connector. The encoder also has a JST connector. But this has no cable. The cable from the motor control system is connected directly to the encoder.
